Automotive ethernet is increasingly the preferred networking and cabling technology for in-vehicle communications. Ethernet communications architecture within a vehicle reduces the need for traditional cabling and enabling weight savings and reduced connectivity costs. Additionally, the architecture enables many types of advanced data-driven systems from vehicular diagnostics and safety systems, all the way to semi-autonomous and autonomous driving capabilities.
Why Automotive Ethernet?
Automotive Ethernet is the next generation of data cables to support a plethora of autonomous safety systems in today’s modern vehicles. Key benefits include:
- Significantly faster data speeds e.g. for applications incorporating cameras and other high-bandwidth devices beyond the capabilities of CAN bus cabling.
- Able to perform in harsh or extreme environments
- Excellent data integrity and performance.
- Tailored electrical and physical requirements for the automotive industry, including withstanding the effects of heat aging
- Carries low-voltage power to devices connected in the vehicle, eliminating additional power wiring.
- Data and physical standards are being defined by multiple industry consortiums and entities including IEEE802.3, the OPEN Alliance, SAE J-3117 and ISO 19652-12.
Automotive Ethernet Cabling
Automotive Ethernet is available in jacketed or un-jacketed and shielded or unshielded variations. Smaller sizes are more commonly used in passenger vehicles, while larger more rugged sizes are used in commercial vehicles.
Key requirements include:
- Data rates of 100BASE-T1 and 1000BASE-T1
- Maximum node lengths of 15 meters for 100BASE-T1 and 15 meters / 20 meters for 1000BASE-T1
- Temperature ranges up to 105 degrees Celsius
Contact or chat Lapp Tannehill today with any questions you may have about Automotive Ethernet cables.
Automotive Ethernet Cables
Automotive Ethernet is increasingly the preferred networking and cabling technology for in-vehicle communications. Ethernet communications architecture within a vehicle reduces the need for traditional cabling, enabling weight savings and reduced connectivity costs. Additionally, the architecture enables many types of advanced data-driven systems, from vehicular diagnostics and safety systems, to semi-autonomous and autonomous driving capabilities.
Why Automotive Ethernet?
Automotive Ethernet is the next generation of data cables to support a plethora of autonomous safety systems in today’s modern vehicles. Key benefits include:
- Significantly faster data speeds e.g. for applications incorporating cameras and other high-bandwidth devices beyond the capabilities of CAN bus cabling.
- Able to perform in harsh or extreme environments
- Excellent data integrity and performance.
- Tailored electrical and physical requirements for the automotive industry, including withstanding the effects of heat aging
- Carries low-voltage power to devices connected in the vehicle, eliminating additional power wiring.
- Data and physical standards are being defined by multiple industry consortiums and entities, including IEEE802.3, the OPEN Alliance, SAE J-3117 and ISO 19652-12.
Automotive Ethernet Cabling
Automotive Ethernet is available in jacketed or un-jacketed and shielded or unshielded variations. Smaller sizes are more commonly used in passenger vehicles, while larger, more rugged sizes are used in commercial vehicles.
Key requirements include:
- Data rates of 100BASE-T1 and 1000BASE-T1
- Maximum node lengths of 15 meters for 100BASE-T1 and 15 meters / 20 meters for 1000BASE-T1
- Temperature ranges up to 105 degrees Celsius
Contact or chat LAPP Tannehill today with any questions you may have about Automotive Ethernet cables.
-
CHA15900 - DATARAD® Automotive Ethernet - .13mm² Conductor - .16mm Strand - BlackPart #: CHA15900
Mfg #: 15900
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .16mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 2.44
VOLTAGE: 60V
- CHA15405 - DATARAD® Automotive Ethernet - .13mm² Conductor - .16mm Strand - Black
Part #: CHA15405
Mfg #: 15405
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .16mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 2.44
VOLTAGE: 60V
- CHA15185 - DATARAD® Automotive Ethernet - .35mm² Conductor - .25mm Strand - Black
Part #: CHA15185
Mfg #: 15185
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .25mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 2.59
VOLTAGE: 60V
- CHA15813 - DATARAD® Automotive Ethernet - .35mm² Conductor - .25mm Strand - Black
Part #: CHA15813
Mfg #: 15813
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .25mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 3.27
VOLTAGE: 60V
- CHA15860 - DATARAD® Automotive Ethernet - .35mm² Conductor - .25mm Strand - Black
Part #: CHA15860
Mfg #: 15860
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .25mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 2.59
VOLTAGE: 60V
- CHA15816 - DATARAD® Automotive Ethernet - .35mm² Conductor - .25mm Strand - Black
Part #: CHA15816
Mfg #: 15816
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .25mm
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 3.51
VOLTAGE: 60V
- CHA15958 - DATARAD® Automotive Ethernet - .35mm² Conductor - .25mm Strand - Black
Part #: CHA15958
Mfg #: 15958
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: .25mm
SHIELDING: Shielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 5.80
VOLTAGE: 60V
- DATARAD® Rugged Automotive Ethernet 2 Twisted Pair - .75mm² Conductor - 19/.23mm Strand
Part #: CHA-E-E-0-75-2-J-U
Mfg #: E-E-0.75-2-J-U
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: 19/.23
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 8.80
VOLTAGE: 60V
- DATARAD® Rugged Automotive Ethernet 2 Twisted Pair - .50mm² Conductor - 19/.18mm Strand
Part #: CHA-E-E-0-50-2-J-U
Mfg #: E-E-0.50-2-J-U
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: 19/.18
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 7.60
VOLTAGE: 60V
- DATARAD® Rugged Automotive Ethernet 2 Twisted Pair - .75mm² Conductor - 19/.23mm Strand
Part #: CHA-E-E-0-75-2-J-U-150
Mfg #: E-E-0.75-2-J-U- 150
Manufacturer: Champlain CableCONDUCTOR STRANDING: Stranded
STRAND COUNT: 19/.23
SHIELDING: Unshielded
CONDUCTOR MATERIAL: Bare Copper
NOMINAL OD (MM): 8.80
VOLTAGE: 60V
